胶质母细胞瘤复发相关基因的筛选、表达和临床预后分析

doi:10.19401/j.cnki.1007-3639.2022.01.002

摘要/Abstract

摘要：

背景与目的：脑胶质瘤是常见的中枢神经系统原发性恶性脑肿瘤之一,胶质母细胞瘤恶性程度高、侵袭性强、容易复发,复发后患者的预后极差。筛选胶质母细胞瘤复发相关的基因,并分析其在胶质瘤中的表达、临床病理学参数和预后的关系。方法：通过对GEO数据库中胶质母细胞瘤相关数据集进行挖掘,筛选包含胶质母细胞瘤原发和复发病例的相关数据集,并分析胶质母细胞瘤原发病例和复发病例样本间的差异表达基因（differentially expressed gene,DEG）。对DEG进行基因本体功能和信号富集分析,构架蛋白质相互作用（protein-protein interaction,PPI）网络,筛选Hub基因。通过PPI网络和Venn图筛选关键基因,而后研究使用基因表达谱数据动态分析（Gene Expression Profiling Interactive Analysis,GEPIA）和中国脑胶质瘤基因组图谱（Chinese Glioma Genome Atlas,CGGA）数据库进行关键基因的生存分析和表达分析,分析其表达与胶质瘤临床病理学参数的关系。结果：GSE62153数据集筛选到40个DEG,上调基因34个,下调基因6个。GSE58399数据集筛选到19个DEG,上调基因16个,下调基因3个。GO功能分析结果提示GSE62153的DEG主要参与中枢神经系统发育、髓鞘、肌动蛋白结合及中枢神经系统髓鞘形成等11个生理过程。而GSE58399的DEG主要参与上皮细胞迁移的正调控。京都基因和基因组百科全书（Kyoto Encyclopedia of Genes and Genomes,KEGG）通路富集分析结果显示,GSE62153和GSE58399的DEG存在共同富集—组氨酸代谢。通过STRING数据库,将20个蛋白分子构建成为核心PPI,Hub基因共筛选出10个,分别为MOBP、OPALIN、ERMN、PLP1、MOG、CLDN11、ASPA、TMEM125、KLK6和NKX6-2基因。胶质母细胞瘤复发关键基因筛选结果显示,共有3个基因：ERMN、MOG和MOBP基因。基于癌症基因组图谱（The Cancer Genome Atlas,TCGA）和CGGA数据库胶质瘤数据分析,ERMN、MOG和MOBP基因高表达者预后均优于低表达组,ERMN、MOG和MOBP基因在胶质母细胞瘤组织内表达水平低于对照组织（P<0.001）。ERMN、MOG和MOBP基因在不同世界卫生组织（World Health Organization,WHO）分级（WHOⅡ、Ⅲ和Ⅳ级）组织内表达差异有统计学意义（P<0.001）,且随着胶质母细胞瘤的级别升高,ERMN、MOG和MOBP基因的表达逐渐降低。ERMN、MOG和MOBP基因表达与WHO分级、异柠檬酸脱氢酶（isocitrate dehydrogenase,IDH）状态及临床病理学参数相关（P<0.001）。而MOBP基因表达与患者年龄（P<0.001）及MGMT甲基化状态（P=0.022）相关。结论：ERMN、MOG和MOBP基因可能发挥抑癌基因作用参与胶质瘤复发过程,组氨酸代谢途径可能与甲氨蝶呤治疗敏感性相关。

关键词: 胶质瘤, 生物信息, 生存预后, 复发, 组氨酸代谢

Abstract:

Background and purpose: Glioma is the most common and malignant primary brain tumor in the central nervous system (CNS). Glioblastoma is highly malignant and aggressive, and the prognosis of patients with recurrent glioblastoma is very poor. This study aimed to screen the genes related to the recurrent glioblastoma, and analyze the relationship between their expressions, clinicopathological parameters and prognosis in glioma. Methods: By mining the relevant datasets of the primary and recurrent cases of glioblastoma in the GEO database, the differentially expressed gene (DEG) in the samples of primary and recurrent glioblastomas were screened and analyzed. All DEGs analyses were carried out in ontology function and pathway enrichment. Protein-protein interaction (PPI) network was constructed and used for screening Hub gene. Key genes were intersected by PPI network and Venn diagram, and the Gene Expression Profiling Interactive Analysis (GEPIA) and Chinese Glioma Genome Atlas (CGGA) database were analyzed for association of key gene expressions and survival status. Key genes were furtherly analyzed to determine the relationship between their expressions and clinicopathological parameters of glioma. Results: There were 40 DEG screened in the dataset GSE62153, including 34 up-regulated genes and 6 down-regulated genes. There were 19 DEG screened in the dataset GSE58399, including 16 up-regulated genes and 3 down-regulated genes. Go functional analyses showed that the DEG of GSE62153 were mainly involved in 11 physiological processes, such as central nervous system development, myelin sheath, actin binding, central nervous system myelination. The DEG of GSE58399 were mainly enriched in the positive regulation of epithelial cell migration. The Kyoto Encyclopedia of Genes and Genomes (KEGG) pathway enrichment showed that the datasets GSE62153 and GSE58399 were both enriched in histidine metabolism. By using the STRING database, the core of PPI network was constructed with 20 protein molecules. A total of 10 hub genes were screened, including MOBP, OPALIN, ERMN, PLP1, MOG, CLDN11, ASPA, TMEM125, KLK6 and NKX6-2 gene. The key genes for recurrent glioblastoma were ERMN, MOG and MOBP gene. Based on analyses using The Cancer Genome Atlas (TCGA) and CGGA databases, the prognosis of patients with high expressions of ERMN, MOG and MOBP was favorable compared with the low expression group. The expression levels of key genes in glioblastoma were lower compared with the control tissues (P<0.001). There were significant differences in the expressions of ERMN, MOG and MOBP gene among different World Health Organization (WHO) grades (WHO Ⅱ, Ⅲ and Ⅳ) (P<0.001). As the grade of glioblastoma increased, the expressions of ERMN, MOG and MOBP were decreased gradually. The expressions of ERMN, MOG and MOBP gene were correlated with WHO classification, isocitrate dehydrogenase (IDH) status and clinicopathological characteristics (P<0.001). The expression of MOBP gene was correlated with age (P<0.001) and MGMT methylation status (P=0.022). Conclusion: ERMN, MOG and MOBP gene may function as tumor suppressor genes and participate in the recurrence of glioblastoma. The histidine metabolism pathway may be related to the sensitivity of methotrexate treatment.

Key words: Glioma, Bioinformatics, Survival, Recurrence, Histidine metabolism

中图分类号:

R739.41

林艺, 王策, 康勋, 康庄, 陈峰, 江波, 李文斌. 胶质母细胞瘤复发相关基因的筛选、表达和临床预后分析[J]. 中国癌症杂志, 2022, 32(1): 13-23.

LIN Yi, WANG Ce, KANG Xun, KANG Zhuang, CHEN Feng, JIANG Bo, LI Wenbin. Screening recurrent glioblastoma-related genes and analyzing their gene expressions in association with clinicopathological parameters and prognosis[J]. China Oncology, 2022, 32(1): 13-23.

图/表 11

表1

表2

表 3

表 4

图1

图2

图3

图 4

图5

图6

表 5

参考文献 27

[1]	OSTROM Q T, PATIL N, CIOFFI G, et al. CBTRUS statistical report: primary brain and other central nervous system tumors diagnosed in the United States in 2013-2017[J]. Neuro Oncol, 2020, 22(12 suppl 2): iv1-iv96. doi: 10.1093/neuonc/noaa200
[2]	MEYER M A. Malignant gliomas in adults[J]. N Engl J Med, 2008, 359(17): 1850.
[3]	GRUBER M L, BUSTER W P. Temozolomide in combination with irinotecan for treatment of recurrent malignant glioma[J]. Am J Clin Oncol, 2004, 27(1): 33-38. doi: 10.1097/01.coc.0000045852.88461.80
[4]	BAO Z S, CHEN H M, YANG M Y, et al. RNA-seq of 272 gliomas revealed a novel, recurrent PTPRZ1-MET fusion transcript in secondary glioblastomas[J]. Genome Res, 2014, 24(11): 1765-1773. doi: 10.1101/gr.165126.113
[5]	ZHAO Z, MENG F, WANG W, et al. Comprehensive RNA-seq transcriptomic profiling in the malignant progression of gliomas[J]. Sci Data, 2017, 4: 170024. doi: 10.1038/sdata.2017.24
[6]	NIEDER C, GROSU A L, MOLLS M. A comparison of treatment results for recurrent malignant gliomas[J]. Cancer Treat Rev, 2000, 26(6): 397-409. doi: 10.1053/ctrv.2000.0191
[7]	STUPP R, HEGI M E, MASON W P, et al. Effects of radiotherapy with concomitant and adjuvant temozolomide versus radiotherapy alone on survival in glioblastoma in a randomised phase Ⅲ study: 5-year analysis of the EORTC-NCIC trial[J]. Lancet Oncol, 2009, 10(5): 459-466. doi: 10.1016/S1470-2045(09)70025-7
[8]	AZOULAY M, SANTOS F, SHENOUDA G, et al. Benefit of re-operation and salvage therapies for recurrent glioblastoma multiforme: results from a single institution[J]. J Neurooncol, 2017, 132(3): 419-426. doi: 10.1007/s11060-017-2383-2
[9]	FRIEDMAN H S, PRADOS M D, WEN P Y, et al. Bevacizumab alone and in combination with irinotecan in recurrent glioblastoma[J]. J Clin Oncol, 2009, 27(28): 4733-4740. doi: 10.1200/JCO.2008.19.8721
[10]	KONG D S, LEE J I, PARK K, et al. Efficacy of stereotactic radiosurgery as a salvage treatment for recurrent malignant gliomas[J]. Cancer, 2008, 112(9): 2046-2051. doi: 10.1002/(ISSN)1097-0142
[11]	SCHNELL O, THORSTEINSDOTTIR J, FLEISCHMANN D F, et al. Re-irradiation strategies in combination with bevacizumab for recurrent malignant glioma[J]. J Neurooncol, 2016, 130(3): 591-599. doi: 10.1007/s11060-016-2267-x
[12]	STUPP R, WONG E T, KANNER A A, et al. NovoTTF-100A versus physician's choice chemotherapy in recurrent glioblastoma: a randomised phase Ⅲ trial of a novel treatment modality[J]. Eur J Cancer, 2012, 48(14): 2192-2202. doi: 10.1016/j.ejca.2012.04.011
[13]	WANG J G, CAZZATO E, LADEWIG E, et al. Clonal evolution of glioblastoma under therapy[J]. Nat Genet, 2016, 48(7): 768-776. doi: 10.1038/ng.3590
[14]	NANDEESH B N, NASKAR S, SHASHTRI A H, et al. Recurrent glioblastomas exhibit higher expression of biomarkers with stem-like properties[J]. J Neurosci Rural Pract, 2018, 9(1): 86-91. doi: 10.4103/jnrp.jnrp_417_17
[15]	ZHANG R R, POINTER K B, KUO J S, et al. Mutational analysis reveals the origin and therapy-driven evolution of recurrent glioma[J]. Neurosurgery, 2014, 75(6): N9-10.
[16]	KIM J, LEE I H, CHO H J, et al. Spatiotemporal evolution of the primary glioblastoma genome[J]. Cancer Cell, 2015, 28(3): 318-328. doi: 10.1016/j.ccell.2015.07.013
[17]	SALEK ESFAHANI B, GHARESOURAN J, GHAFOURI-FARD S, et al. Down-regulation of ERMN expression in relapsing remitting multiple sclerosis[J]. Metab Brain Dis, 2019, 34(5): 1261-1266. doi: 10.1007/s11011-019-00429-w
[18]	ZHANG L, XUE Z Y, LIU Q D, et al. Disrupted folate metabolism with anesthesia leads to myelination deficits mediated by epigenetic regulation of ERMN[J]. EBioMedicine, 2019, 43: 473-486. doi: 10.1016/j.ebiom.2019.04.048
[19]	HOMS A, CODINA-SOLÀ M, RODRÍGUEZ-SANTIAGO B, et al. Genetic and epigenetic methylation defects and implication of the ERMN gene in autism spectrum disorders[J]. Transl Psychiatry, 2016, 6(7): e855. doi: 10.1038/tp.2016.120
[20]	LINNINGTON C, WEBB M, WOODHAMS P L. A novel myelin-associated glycoprotein defined by a mouse monoclonal antibody[J]. J Neuroimmunol, 1984, 6(6): 387-396. doi: 10.1016/0165-5728(84)90064-X
[21]	VOURC'H P, ANDRES C. Oligodendrocyte myelin glycoprotein (OMgp): evolution, structure and function[J]. Brain Res Brain Res Rev, 2004, 45(2): 115-124. doi: 10.1016/j.brainresrev.2004.01.003
[22]	KIM S M, WOODHALL M R, KIM J S, et al. Antibodies to MOG in adults with inflammatory demyelinating disease of the CNS[J]. Neurol Neuroimmunol Neuroinflamm, 2015, 2(6): e163. doi: 10.1212/NXI.0000000000000163
[23]	KANAREK N, KEYS H R, CANTOR J R, et al. Histidine catabolism is a major determinant of methotrexate sensitivity[J]. Nature, 2018, 559(7715): 632-636. doi: 10.1038/s41586-018-0316-7
[24]	ROMODANOV A P, ZOZULJA J A, SOSNOV J D, et al. Regional chemotherapy of malignant brain tumors with endolumbar methotrexate injection[J]. Zentralbl Neurochir, 1976, 37(3): 161-167.
[25]	NIERENBERG D, HARBAUGH R, MAURER L H, et al. Continuous intratumoral infusion of methotrexate for recurrent glioblastoma: a pilot study[J]. Neurosurgery, 1991, 28(5): 752-761. doi: 10.1227/00006123-199105000-00023
[26]	李丰展, 盖立平, 杨艳敏, 等. 胶质母细胞瘤术后甲氨蝶呤间质化疗同步放化疗临床观察[J]. 中国实用神经疾病杂志, 2020, 23(17): 1544-1548.
	LI F Z, GAI L P, YANG Y M, et al. Clinical observation on simultaneous sadiotherapy and chemotherapy of methotrexate interstitial chemotherapy after glioblastoma[J]. Chin J Pract Nerv Dis, 2020, 23(17): 1544-1548.
[27]	白玥, 钟晓松, 李文斌. 甲氨蝶呤通过RAS/MAPK/ERK/MYC/CD47信号通路抑制胶质母细胞瘤的生长[J]. 肿瘤代谢与营养电子杂志, 2018, 5(2): 144-150.
	BAI Y, ZHONG X S, LI W B. Glioblastoma progression is inhibited by methotrexate via RAS/MEK/ERK/MYC/CD47 signaling pathways[J]. Electron J Metab Nutr Cancer, 2018, 5(2): 144-150.

Databases	Website
STRING	https://string-db.org/
GEPIA	http://gepia.cancer-pku.cn/
CGGA	http://www.cbioportal.org

Category	Term	Description	Count n (%)	P value	Gene
BP	GO: 0007417	Central nervous system development	4 (12.01)	0.001	SH3GL3, MOG, SH3GL2, KLK6
CC	GO: 0043209	Myelin sheath	4 (12.10)	0.002	CLDN11, MOBP, PLP1, ERMN
MF	GO: 0003779	Actin binding	4 (12.10)	0.011	MYBPC1, MOBP, DAAM2, PHACTR3
BP	GO: 0022010	Central nervous system myelination	2 (6.06)	0.012	NKX6-2, PLP1
BP	GO: 0008366	Axon ensheathment	2 (6.06)	0.012	CLDN11, PLP1
MF	GO: 0008599	Protein phosphatase type 1 regulator activity	2 (6.06)	0.016	PPP1R1B, PHACTR3
MF	GO: 0019911	Structural constituent of myelin sheath	2 (6.06)	0.016	MOBP, PLP1
BP	GO: 0019371	Cyclooxygenase pathway	2 (6.06)	0.018	AKR1C3, PTGDS
MF	GO: 0031432	Titin binding	2 (6.06)	0.023	MYBPC1, CAPN3
BP	GO: 0006796	Phosphate-containing compound metabolic process	2 (6.06)	0.032	ENPP2, LHPP
MF	GO: 0042802	Identical protein binding	5 (15.15)	0.034	CLDN11, SH3GL3, HSPB8, SH3GL2, ETNPPL

Category	Term	Description	Count n (%)	P value	Gene
BP	GO: 0010634	Positive regulation of epithelial cell migration	2 (12.5)	0.027	DOCK5, ENPP2
KEGG	hsa00340	Histidine metabolism	2 (12.5)	0.016	ASPA, CNDP1
